Max. Displacement: 501.5 cc/rev
Max. Flow: 901 LPM
Operating Pressure: 350 Bar/5000 PSI
Side/Rear/Opposing Ports, Mount & Shaft: SAE
Flange, Straight Threaded Port Types
| MODEL SERIES | CC/REV | Max. Cont. pressure (PSI) | Max. Speed (RPM) | Flow @1500 RPM | Case pressure cont. |
|---|---|---|---|---|---|
| P6 | 98.3 | 5000 | 3000 | 148 LPM | 75 PSI |
| P7 | 118.8 | 5000 | 3000 | 178 LPM | 75 PSI |
| P8 | 131.1 | 5000 | 2100 | 197 LPM | 75 PSI |
| P11 | 180.3 | 5000 | 2400 | 269 LPM | 75 PSI |
| P14 | 229.5 | 5000 | 2400 | 344 LPM | 75 PSI |
| P24 | 403.2 | 5000 | 2100 | 606 LPM | 75 PSI |
| P30 | 501.5 | 5000 | 1800 | 753 LPM | 75 PSI |
| PART NUMBER | ACCESSORIES – DESCRIPTION |
|---|---|
| 033-91058-0 | Gold Cup Control Gasket |
| Brand |
|---|
Denison Premier Piston Pump PDF
Max. Displacement: 260 cc/rev
Max. Flow : 548 LPM
Operating Pressure: 420 Bar/6000 PSI
Mount & Shaft Type: SAE, ISO, DIN
Port Type: Flange, Opposing, SAE, ISO
Continuous Pressure Up To: 350 Bar
Thru-Shaft Capability
Low Outlet Flow Pulsation
7 Stand Control Options
Maximum Outlet Pressure: 5000 PSI
Parker PAVC Pump Catalogue PDF
Maximum Displacement From: 33 – 100 cc/rev
2 Bolt SAE Mount/Port Connection
Maximum Flow Rate: 260 LPM/69 GPM
Flange & Straight Threaded Side & Rear Ports
